#3265 USED 2014 QUICKDRILL 120
$150,000.00
The 2014 Quickdrill 120 is a precision CNC deep-hole drilling and tapping center with 47″ × 20″ travels, a 40-taper 8,000 rpm spindle, and automatic tool changer—engineered for fast, accurate drilling in steel, aluminum, and alloys.
The 2014 Quickdrill 120 is a high-performance CNC drilling and tapping center designed for fast and accurate hole production in steel, aluminum, and alloy components. Engineered for productivity and precision, it combines rigid construction with smooth axis motion and powerful spindle performance. With a work envelope of 47″ (X), 20″ (Y), and 20″ (Z), the Quickdrill 120 offers excellent capacity for drilling, tapping, and light milling operations in manufacturing and fabrication environments.
Built on a cast-iron frame with linear guideways and precision ball screws, the machine provides exceptional stability and accuracy even under continuous load. The 40-taper spindle, running up to 8,000 rpm, delivers the speed and torque required for high-efficiency drilling and tapping. A 16-position automatic tool changer and modern CNC control system ensure quick setup and repeatable performance for high-throughput applications.
| Specification | Value |
|---|---|
| Manufacturer | Quickdrill |
| Model | 120 |
| Year | 2014 |
| Machine Type | CNC Drilling and Tapping Center |
| X-Axis Travel | 47″ (1,200 mm) |
| Y-Axis Travel | 20″ (500 mm) |
| Z-Axis Travel | 20″ (500 mm) |
| Table Size | 51″ × 20″ (1,300 × 500 mm) |
| Spindle Taper | CAT-40 |
| Spindle Speed | 8,000 rpm |
| Spindle Motor | 15 hp (11 kW) |
| Tool Changer | 16 ATC |
| Rapid Traverse | 1,200 ipm (30 m/min) |
| Control | Fanuc CNC Control |
| Coolant System | Through-spindle and flood coolant |
| Machine Weight | ~11,000 lb (5,000 kg) |
| Final Listing Price | Request Quote |
Features & Options
- 47″ × 20″ × 20″ travel capacity for drilling and tapping versatility
- 8,000 rpm CAT-40 spindle with 15 hp drive motor
- 16-position automatic tool changer for fast cycle times
- Rigid cast-iron base for vibration-free accuracy
- Fanuc CNC control with conversational programming
- Through-spindle coolant system for deep-hole drilling
- Linear guideways for high-speed positioning and repeatability
- Ideal for production drilling, tapping, and light milling operations
Specifications are typical for the 2014 Quickdrill 120 model. Always verify actual configuration and capabilities with the manufacturer or machine nameplate.
